Online Monitoring solution for Electric Vehicle Drive System

Scene Introduction

Since the State Council released the "Development Plan for Energy Conservation and New Energy Vehicle Industry (2012-2020)" in 2012, China has adhered to the strategy of pure electric drive, and the development of the new energy vehicle industry has achieved great success, becoming one of the important forces for the transformation of the world's automotive industry.


In 2020, the General Office of the State Council issued the Notice on the Development Plan for the New Energy Vehicle Industry (2021-2035) (Guobanfa [2020] No. 39), hereinafter referred to as the "Plan". The Plan points out that the development of new energy vehicles is a necessary path for China to move from a major automobile country to a strong automobile country, and is a strategic measure to address climate change and promote green development


In the past two years, the development of electric vehicles in China has accelerated, and the production and sales of new energy vehicles have increased significantly. In 2021, the domestic production and sales of new energy vehicles reached 358.4 × 104 and 356.0 × 104 respectively, with a year-on-year growth rate of 160%. The sales penetration rate was 13.6%, exceeding the key point of 10%. Domestic new energy vehicles entered the growth stage from the import period. In 2022, the domestic production and sales of new energy vehicles will further soar, reaching 705.8 × 104 and 688.7 × 104 units, with year-on-year growth rates of 96.9% and 93.5% respectively, ranking first in the world for 8 consecutive years. The annual sales penetration rate is as high as 25.6%


Industry demand

With the rapid development of the electric vehicle market, the requirements for the performance and reliability of electric drive systems have become more stringent. Electric vehicle manufacturers urgently need an efficient online monitoring solution to meet the demand for high-performance and high safety electric drive systems in electric vehicles.


The reliability of core components such as bus capacitors, bus terminals, and power modules in electric vehicle drive systems is directly related to the power transmission and safety of the vehicle. The industry has put forward higher requirements for the stability and lifespan of these components.


The demand for real-time access to performance and status information of core components of electric drive systems is becoming increasingly urgent for electric vehicle operators and owners, in order to make more informed driving decisions while reducing maintenance costs.


solution

The online monitoring solution for electric vehicle electric drive systems focuses on monitoring the electric drive system and its key components, including bus capacitors, bus terminals, and power modules. This solution provides a comprehensive understanding of the health status of electric vehicle electric drive systems by monitoring and analyzing the performance of electric drive systems and their components in real time.

Solution 1
The online monitoring scheme for electric vehicle electric drive system adopts advanced data analysis technology. Through a real-time monitoring system, potential problems can be detected in a timely manner during vehicle operation.
Solution 2
By introducing machine learning algorithms and analyzing a large amount of driving data and historical performance data of core components of electric vehicle electric drive systems, it is possible to predict future faults and problems. This predictive monitoring helps to detect potential faults in advance and provide more timely maintenance recommendations for car owners and manufacturers.
Solution 3
The application of cloud platforms enables real-time transmission of monitoring data to remote servers, allowing manufacturers and car owners to access real-time information about the core components of electric vehicle drive systems anytime and anywhere. This remote monitoring function helps manufacturers improve product design and provide more accurate after-sales service, while also providing car owners with a more convenient driving experience.
